A FEARSOME FIGHTER MADE FUN TO BUILD
The Balsa Basics BF-109 is an intermediate level flyer that is easy to build and friendly to fly.
Unlike other warbird models out there, this one has a very light wing-loading and gentle characteristics.
Although not for beginner pilots (for that see the Balsa Basics Cub), this would make for a great first warbird.
Like the real steel, the Balsa Basics Messerschmitt BF-109 is quick, clean and responsive in the air.
Easy to Build
We have designed this model to go together quickly and with minimum fuss. Precision laser cut parts fit together to form the tapered wing of the 109 with a spar and doublers cleverly sandwiching each wing rib.
Likewise, the fuselage is built up using self-jigging components that interlock to form the nose and cockpit of the aircraft.
Solid balsa fuselage sides and more formers bring the tail together to capture that iconic 109 feel in a simple yet effective way.
More Detailed Than You Might Think
This fun-scale model of the BF-109 packs in just the right amount of detail: exhaust stacks, structural tail supports, vacuum-formed plastic canopy, self-adhesive markings and prop spinner are included as standard.
Easy Battery Access
There’s plenty of room in the battery compartment for a 3s LiPo battery up to a 2200 (which is the recommended size for this model).
To do away with complex and fragile retracts, the Balsa Basics BF-109 is a belly lander. A quick underarm launch and you’re up in the air with landings over grass in a field or park a cinch.
INCLUDED IN YOUR KIT
- Laser cut components (including 2x ply sheets, balsa sheets, balsa strip wood sheet, and thin ply sheet with control horns)
- 18swg (1.2mm) x 19 inch (480mm) piano wire pushrods (no z bend)
- 18swg (1.2mm) x 4 inch (100mm) piano wire aileron pushrods (no z bend)
- 1/8th (3.175mm) x 9inch (230mm) hardwood dowel
- Vacuum-formed scale plastic canopy
- 4 x M3 T-nuts
- 4 x M3 bolts
- 12 x Mylar hinges
- 4 x Rubber Wing bands
- 1 x Emax 2215/09 1180kv Motor
- 1 x 30A ESC
- 2 x Emax 1045 propeller
- 56mm Spinner
- 4 x 9g Servos
- Motor hardware
- Servo extension wires
- RadioLink 8ch Transmitter/Receiver
- Grey/Yellow Polyester heatshrink covering
YOU WILL NEED
- 1x 11.1V 2200mah 20C 3s Lipo Battery with XT60 connector
- Battery charger
- Modelling iron or alternative to attach covering
